MP108FDA - Power Operational Amplifier, 200V 10A, 100W, "A" Grade
The MP108 operational amplifier is a surface mount constructed component that provides a cost effective solution in many industrial applications. The MP108 offers outstanding performance that rivals much more expensive hybrid components yet has a footprint of only 4 sq in. The MP108 has many optional features such as four-wire current limit sensing and external compensation. The 300 kHz power bandwidth and 10 amp output of the MP108 makes it a good choice for piezo transducer drive applications.
The MP108 is built on a thermally conductive but electrically insulating substrate that can be mounted to a heat sink.
FEATURES
• LOW COST
• HIGH VOLTAGE - 200 VOLTS
• HIGH OUTPUT CURRENT - 10 AMPS
• 100 WATT DISSIPATION CAPABILITY
• 300kHz POWER BANDWIDTH
APPLICATIONS
• INKJET PRINTER HEAD DRIVE
• PIEZO TRANSDUCER DRIVE
• INDUSTRIAL INSTRUMENTATION
• REFLECTOMETERS
• ULTRA-SOUND TRANSDUCER DRIVE
- APEX Microtechnology product -
