Webinar Reducing Oscillation in Analog Designs - July 28th - 11a to 12p - MST

When integrating analog drivers, designers are often faced with unwanted oscillation caused by instability.

We would like to invite you to Apex Microtechnology’s webinar, Reducing Oscillation in Analog Designs. This webinar will discuss simple techniques for maintaining a stable circuit.

Date: July 28th, 2021
Time: 11a – 12p MST
Registration Link

In this webinar, Apex Microtechnology will discuss Loop Stability and examine the following issues:

  • Why capacitive loads create stability problems in standard op amp circuits.
  • Closed loop gain (1/ß) and open loop gain (AOL) and their relationships to stability.
  • How capacitors impact the open loop gain (AOL) curve.
  • Multiple ways to adjust the closed loop gain (1/ß) and the open loop gain (AOL) responses to regain phase margin and stability, along with the advantages and disadvantages of each technique.

After the presentation, there will be a live Q&A for the audience. A recording of the session will be made available to all registrants. If you would like to attend but are unable to join us at the scheduled meeting time, please register and a recording will still be provided to you.


About the Presenter:

Alejandro (Alex) Castro is a Field Applications Engineer for Apex Microtechnology. He works to ensure the highest level of engineering support for the integration of Apex components into a wide range of systems. Alex supports a diverse portfolio of applications that span the Defense, Aerospace, Medical, Semi-Cap, Industrial, and Digital Printing industries. Alex holds a BS in Electronic Communications Engineering from ITT Technical Institute.
