Product specifications
EK14 - Evaluation Kit for DP Package Op Amps
** This EK does NOT contain the actual amplifier device, so that needs to be ordered separately **
The EK14 evaluation kit provides a convenient way to breadboard circuits using Apex Precision Power power op amps packaged in the 12-pin SIP03 package. The amplifier may be mounted vertically with the HS20 heat sink, or horizontally. Connections are provided for required power supply bypassing, external compensation components, as well as current limit resistors. A large area for component mounting provides flexibility and makes a multitude of circuit configurations possible.
- APEX Microtechnology product -
